Newhaven Display International Page 24 of 39
NHD-2
40128WG-BYGH-VZ#000C
X: invalid
If the graphic area setting is set to match the desired number of columns on the LCD, the addressing scheme
will be automatically modified so the start address of each line equals the end address of the previous line
+1. Mode set
CODE FUNCTION OPERAND
1000×000 OR Mode
1000×001 EXOR Mode
1000×011 AND Mode
1000×100 TEXT ATTRIBUTE Mode
10000×××
Internal Character Generator Mode
10001×××
External Character Generator Mode
The display mode is defined by this command. The display mode does not change until the next command is
sent. The logical OR, EXOR, AND of text or graphic display can be displayed. In Internal Character Generator
mode, character codes 00H to 7FH are assigned to the built-in character generator ROM. The character codes
80H to FFH are automatically assigned to the external character generator RAM.
(Example)
(Note)Attribute functions can only be applied to text display, since the attribute data is placed in the graphic RAM
area.
Attribute function
The attribute operations are Reverse display, Character blink and Inhibit. The attribute data is written into the
graphic area which was defined by the Set Control Word command. Only text display is possible in Attribute
Function mode; graphic display is automatically disabled. However, the Display Mode command must be used to
